3D数学 AABB轴对齐矩形边界框

1. 几何图元

直线：由两个向量定义直线的方向

射线：由两个向量定义直线的方向，其中一个向量定义射线的起点

球和圆

矩形边界框（AABB）

2. AABB（轴对齐矩形边界框）C++实现

///////////////////////////////////////////////////////////////////////////////// 3D Math Primer for Games and Graphics Development//// AABB3.h - Declarations for class AABB3//// Visit gamemath.com for the latest version of this file.//// For more details, see AABB3.cpp///////////////////////////////////////////////////////////////////////////////#ifndef __AABB3_H_INCLUDED__#define __AABB3_H_INCLUDED__#ifndef __VECTOR3_H_INCLUDED__    #include "Vector3.h"#endifclass Matrix4x3;//---------------------------------------------------------------------------// class AABB3//// Implement a 3D axially aligned bounding boxclass AABB3 {public:// Public data    // Min and max values.  Pretty simple.    Vector3 min;    Vector3 max;// Query for dimentions    Vector3 size() const { return max - min; }    float   xSize() { return max.x - min.x; }    float   ySize() { return max.y - min.y; }    float   zSize() { return max.z - min.z; }    Vector3 center() const { return (min + max) * .5f; }    // Fetch one of the eight corner points.  See the    // .cpp for numbering conventions    Vector3 corner(int i) const;// Box operations    // "Empty" the box, by setting the values to really    // large/small numbers    void    empty();    // Add a point to the box    void    add(const Vector3 &p);    // Add an AABB to the box    void    add(const AABB3 &box);    // Transform the box and compute the new AABB    void    setToTransformedBox(const AABB3 &box, const Matrix4x3 &m);// Containment/intersection tests    // Return true if the box is enmpty    bool    isEmpty() const;    // Return true if the box contains a point    bool    contains(const Vector3 &p) const;    // Return the closest point on this box to another point    Vector3 closestPointTo(const Vector3 &p) const;    // Return true if we intersect a sphere    bool    intersectsSphere(const Vector3 &center, float radius) const;    // Parametric intersection with a ray.  Returns >1 if no intresection    float   rayIntersect(const Vector3 &rayOrg, const Vector3 &rayDelta,        Vector3 *returnNormal = 0) const;    // Classify box as being on one side or the other of a plane    int classifyPlane(const Vector3 &n, float d) const;    // Dynamic intersection with plane    float   intersectPlane(const Vector3 &n, float planeD,        const Vector3 &dir) const;};// Check if two AABBs intersect, and return true if so.  Optionally return// the AABB of their intersection if an intersection is detectedbool    intersectAABBs(const AABB3 &box1, const AABB3 &box2,    AABB3 *boxIntersect = 0);// Return parametric point in time when a moving AABB collides// with a stationary AABB.  Returns > 1 if no intersectionfloat   intersectMovingAABB(    const AABB3 &stationaryBox,    const AABB3 &movingBox,    const Vector3 &d);/////////////////////////////////////////////////////////////////////////////#endif // #ifndef __AABB3_H_INCLUDED__

///// 3D Math Primer for Games and Graphics Development//// AABB3.cpp - Implementation for class AABB3//// Visit gamemath.com for the latest version of this file.//// For more details, see Chapter 12///#include

    #include

     #include "AABB3.h"#include "Matrix4x3.h"#include "CommonStuff.h"///// class AABB3 member functions/////---------------------------------------------------------------------------// AABB3::corner//// Return one of the 8 corner points.  The points are numbered as follows:////            6                                7//              ------------------------------//             /|                           /|//            / |                          / |//           /  |                         /  |//          /   |                        /   |//         /    |                       /    |//        /     |                      /     |//       /      |                     /      |//      /       |                    /       |//     /        |                   /        |//  2 /         |                3 /         |//   /----------------------------/          |//   |          |                 |          |//   |          |                 |          |      +Y//   |        4 |                 |          | //   |          |-----------------|----------|      |//   |         /                  |         /  5    |//   |        /                   |        /        |       +Z//   |       /                    |       /         |//   |      /                     |      /          |     ///   |     /                      |     /           |    ///   |    /                       |    /            |   ///   |   /                        |   /             |  ///   |  /                         |  /              | ///   | /                          | /               |///   |/                           |/                ----------------- +X//   ------------------------------//  0                              1//// Bit 0 selects min.x vs. max.x// Bit 1 selects min.y vs. max.y// Bit 2 selects min.z vs. max.zVector3 AABB3::corner(int i) const {    // Make sure index is in range...    assert(i >= 0);    assert(i <= 7);    // Return it    return Vector3(        (i & 1) ? max.x : min.x,        (i & 2) ? max.y : min.y,        (i & 4) ? max.z : min.z    );}//---------------------------------------------------------------------------// AABB3::empty//// "Empty" the box, by setting the values to really// large/small numbersvoid    AABB3::empty() {    const float kBigNumber = 1e37f;    min.x = min.y = min.z = kBigNumber;    max.x = max.y = max.z = -kBigNumber;}//---------------------------------------------------------------------------// AABB3::add//// Add a point to the boxvoid    AABB3::add(const Vector3 &p) {    // Expand the box as necessary to contain the point.    if (p.x < min.x) min.x = p.x;    if (p.x > max.x) max.x = p.x;    if (p.y < min.x) min.y = p.y;    if (p.y > max.x) max.y = p.y;    if (p.z < min.x) min.z = p.z;    if (p.z > max.x) max.z = p.z;}//---------------------------------------------------------------------------// AABB3::add//// Add an AABB to the boxvoid    AABB3::add(const AABB3 &box) {    // Expand the box as necessary.    if (box.min.x < min.x) min.x = box.min.x;    if (box.min.x > max.x) max.x = box.min.x;    if (box.min.y < min.x) min.y = box.min.y;    if (box.min.y > max.x) max.y = box.min.y;    if (box.min.z < min.x) min.z = box.min.z;    if (box.min.z > max.x) max.z = box.min.z;}//---------------------------------------------------------------------------// AABB3::setToTransformedBox//// Transform the box and compute the new AABB.  Remember, this always// results in an AABB that is at least as big as the origin, and may be// considerably bigger.//// See 12.4.4void    AABB3::setToTransformedBox(const AABB3 &box, const Matrix4x3 &m) {    // If we're empty, then bail    if (box.isEmpty()) {        empty();        return;    }    // Start with the translation portion    min = max = getTranslation(m);    // Examine each of the 9 matrix elements    // and compute the new AABB    if (m.m11 > 0.0f) {        min.x += m.m11 * box.min.x; max.x += m.m11 * box.max.x;    } else {        min.x += m.m11 * box.max.x; max.x += m.m11 * box.min.x;    }    if (m.m12 > 0.0f) {        min.y += m.m12 * box.min.x; max.y += m.m12 * box.max.x;    } else {        min.y += m.m12 * box.max.x; max.y += m.m12 * box.min.x;    }    if (m.m13 > 0.0f) {        min.z += m.m13 * box.min.x; max.z += m.m13 * box.max.x;    } else {        min.z += m.m13 * box.max.x; max.z += m.m13 * box.min.x;    }    if (m.m21 > 0.0f) {        min.x += m.m21 * box.min.y; max.x += m.m21 * box.max.y;    } else {        min.x += m.m21 * box.max.y; max.x += m.m21 * box.min.y;    }    if (m.m22 > 0.0f) {        min.y += m.m22 * box.min.y; max.y += m.m22 * box.max.y;    } else {        min.y += m.m22 * box.max.y; max.y += m.m22 * box.min.y;    }    if (m.m23 > 0.0f) {        min.z += m.m23 * box.min.y; max.z += m.m23 * box.max.y;    } else {        min.z += m.m23 * box.max.y; max.z += m.m23 * box.min.y;    }    if (m.m31 > 0.0f) {        min.x += m.m31 * box.min.z; max.x += m.m31 * box.max.z;    } else {        min.x += m.m31 * box.max.z; max.x += m.m31 * box.min.z;    }    if (m.m32 > 0.0f) {        min.y += m.m32 * box.min.z; max.y += m.m32 * box.max.z;    } else {        min.y += m.m32 * box.max.z; max.y += m.m32 * box.min.z;    }    if (m.m33 > 0.0f) {        min.z += m.m33 * box.min.z; max.z += m.m33 * box.max.z;    } else {        min.z += m.m33 * box.max.z; max.z += m.m33 * box.min.z;    }}//---------------------------------------------------------------------------// AABB3::isEmpty//// Return true if the box is enmptybool    AABB3::isEmpty() const {    // Check if we're inverted on any axis    return (min.x > max.x) || (min.y > max.y) || (min.z > max.z);}//---------------------------------------------------------------------------// AABB3::contains//// Return true if the box contains a pointbool    AABB3::contains(const Vector3 &p) const {    // Check for overlap on each axis    return        (p.x >= min.x) && (p.x <= max.x) &&        (p.y >= min.y) && (p.y <= max.y) &&        (p.z >= min.z) && (p.z <= max.z);}//---------------------------------------------------------------------------// AABB3::closestPointTo//// Return the closest point on this box to another pointVector3 AABB3::closestPointTo(const Vector3 &p) const {    // "Push" p into the box, on each dimension    Vector3 r;    if (p.x < min.x) {        r.x = min.x;    } else if (p.x > max.x) {        r.x = max.x;    } else {        r.x = p.x;    }    if (p.y < min.y) {        r.y = min.y;    } else if (p.y > max.y) {        r.y = max.y;    } else {        r.y = p.y;    }    if (p.z < min.z) {        r.z = min.z;    } else if (p.z > max.z) {        r.z = max.z;    } else {        r.z = p.z;    }    // Return it    return r;}//---------------------------------------------------------------------------// AABB3::intersectsSphere//// Return true if we intersect a sphere.  Uses Arvo's algorithm.bool    AABB3::intersectsSphere(const Vector3 &center, float radius) const {    // Find the closest point on box to the point    Vector3 closestPoint = closestPointTo(center);    // Check if it's within range    return distanceSquared(center, closestPoint) < radius*radius;}//---------------------------------------------------------------------------// AABB3::rayIntersect//// Parametric intersection with a ray.  Returns parametric point// of intsersection in range 0...1 or a really big number (>1) if no// intersection.//// From "Fast Ray-Box Intersection," by Woo in Graphics Gems I,// page 395.//// See 12.9.11float   AABB3::rayIntersect(    const Vector3 &rayOrg,      // orgin of the ray    const Vector3 &rayDelta,    // length and direction of the ray    Vector3 *returnNormal       // optionally, the normal is returned) const {    // We'll return this huge number if no intersection    const float kNoIntersection = 1e30f;    // Check for point inside box, trivial reject, and determine parametric    // distance to each front face    bool inside = true;    float xt, xn;    if (rayOrg.x < min.x) {        xt = min.x - rayOrg.x;        if (xt > rayDelta.x) return kNoIntersection;        xt /= rayDelta.x;        inside = false;        xn = -1.0f;    } else if (rayOrg.x > max.x) {        xt = max.x - rayOrg.x;        if (xt < rayDelta.x) return kNoIntersection;        xt /= rayDelta.x;        inside = false;        xn = 1.0f;    } else {        xt = -1.0f;    }    float yt, yn;    if (rayOrg.y < min.y) {        yt = min.y - rayOrg.y;        if (yt > rayDelta.y) return kNoIntersection;        yt /= rayDelta.y;        inside = false;        yn = -1.0f;    } else if (rayOrg.y > max.y) {        yt = max.y - rayOrg.y;        if (yt < rayDelta.y) return kNoIntersection;        yt /= rayDelta.y;        inside = false;        yn = 1.0f;    } else {        yt = -1.0f;    }    float zt, zn;    if (rayOrg.z < min.z) {        zt = min.z - rayOrg.z;        if (zt > rayDelta.z) return kNoIntersection;        zt /= rayDelta.z;        inside = false;        zn = -1.0f;    } else if (rayOrg.z > max.z) {        zt = max.z - rayOrg.z;        if (zt < rayDelta.z) return kNoIntersection;        zt /= rayDelta.z;        inside = false;        zn = 1.0f;    } else {        zt = -1.0f;    }    // Inside box?    if (inside) {        if (returnNormal != NULL) {            *returnNormal = -rayDelta;            returnNormal->normalize();        }        return 0.0f;    }    // Select farthest plane - this is    // the plane of intersection.    int which = 0;    float t = xt;    if (yt > t) {        which = 1;        t = yt;    }    if (zt > t) {        which = 2;        t = zt;    }    switch (which) {        case 0: // intersect with yz plane        {            float y = rayOrg.y + rayDelta.y*t;            if (y < min.y || y > max.y) return kNoIntersection;            float z = rayOrg.z + rayDelta.z*t;            if (z < min.z || z > max.z) return kNoIntersection;            if (returnNormal != NULL) {                returnNormal->x = xn;                returnNormal->y = 0.0f;                returnNormal->z = 0.0f;            }        } break;        case 1: // intersect with xz plane        {            float x = rayOrg.x + rayDelta.x*t;            if (x < min.x || x > max.x) return kNoIntersection;            float z = rayOrg.z + rayDelta.z*t;            if (z < min.z || z > max.z) return kNoIntersection;            if (returnNormal != NULL) {                returnNormal->x = 0.0f;                returnNormal->y = yn;                returnNormal->z = 0.0f;            }        } break;        case 2: // intersect with xy plane        {            float x = rayOrg.x + rayDelta.x*t;            if (x < min.x || x > max.x) return kNoIntersection;            float y = rayOrg.y + rayDelta.y*t;            if (y < min.y || y > max.y) return kNoIntersection;            if (returnNormal != NULL) {                returnNormal->x = 0.0f;                returnNormal->y = 0.0f;                returnNormal->z = zn;            }        } break;    }    // Return parametric point of intersection    return t;}//---------------------------------------------------------------------------// AABB3::classifyPlane//// Perform static AABB-plane intersection test.  Returns://// <0   Box is completely on the BACK side of the plane// >0   Box is completely on the FRONT side of the plane// 0    Box intersects the planeint AABB3::classifyPlane(const Vector3 &n, float d) const {    // Inspect the normal and compute the minimum and maximum    // D values.    float   minD, maxD;    if (n.x > 0.0f) {        minD = n.x*min.x; maxD = n.x*max.x;    } else {        minD = n.x*max.x; maxD = n.x*min.x;    }    if (n.y > 0.0f) {        minD += n.y*min.y; maxD += n.y*max.y;    } else {        minD += n.y*max.y; maxD += n.y*min.y;    }    if (n.z > 0.0f) {        minD += n.z*min.z; maxD += n.z*max.z;    } else {        minD += n.z*max.z; maxD += n.z*min.z;    }    // Check if completely on the front side of the plane    if (minD >= d) {        return +1;    }    // Check if completely on the back side of the plane    if (maxD <= d) {        return -1;    }    // We straddle the plane    return 0;}//---------------------------------------------------------------------------// AABB3::intersectPlane//// Perform dynamic AABB-plane intersection test.//// n        is the plane normal (assumed to be normalized)// planeD   is the D value of the plane equation p.n = d// dir      dir is the direction of movement of the AABB.//// The plane is assumed to be stationary.//// Returns the parametric point of intersection - the distance traveled// before an intersection occurs.  If no intersection, a REALLY big// number is returned.  You must check against the length of the// displacement.//// Only intersections with the front side of the plane are detectedfloat   AABB3::intersectPlane(    const Vector3   &n,    float       planeD,    const Vector3   &dir) const {    // Make sure they are passing in normalized vectors    assert(fabs(n*n - 1.0) < .01);    assert(fabs(dir*dir - 1.0) < .01);    // We'll return this huge number if no intersection    const float kNoIntersection = 1e30f;    // Compute glancing angle, make sure we are moving towards    // the front of the plane    float   dot = n * dir;    if (dot >= 0.0f) {        return kNoIntersection;    }    // Inspect the normal and compute the minimum and maximum    // D values.  minD is the D value of the "frontmost" corner point    float   minD, maxD;    if (n.x > 0.0f) {        minD = n.x*min.x; maxD = n.x*max.x;    } else {        minD = n.x*max.x; maxD = n.x*min.x;    }    if (n.y > 0.0f) {        minD += n.y*min.y; maxD += n.y*max.y;    } else {        minD += n.y*max.y; maxD += n.y*min.y;    }    if (n.z > 0.0f) {        minD += n.z*min.z; maxD += n.z*max.z;    } else {        minD += n.z*max.z; maxD += n.z*min.z;    }    // Check if we're already completely on the other    // side of the plane    if (maxD <= planeD) {        return kNoIntersection;    }    // Perform standard raytrace equation using the    // frontmost corner point    float   t = (planeD - minD) / dot;    // Were we already penetrating?    if (t < 0.0f) {        return 0.0f;    }    // Return it.  If > l, then we didn't hit in time.  That's    // the condition that the caller should be checking for.    return t;}///// Global nonmember code/////---------------------------------------------------------------------------// intersectAABBs//// Check if two AABBs intersect, and return true if so.  Optionally return// the AABB of their intersection if an intersection is detectedbool    intersectAABBs(    const AABB3 &box1,    const AABB3 &box2,    AABB3 *boxIntersect) {    // Check for no overlap    if (box1.min.x > box2.max.x) return false;    if (box1.max.x < box2.min.x) return false;    if (box1.min.y > box2.max.y) return false;    if (box1.max.y < box2.min.y) return false;    if (box1.min.z > box2.max.z) return false;    if (box1.max.z < box2.min.z) return false;    // We have overlap.  Compute AABB of intersection, if they want it    if (boxIntersect != NULL) {        boxIntersect->min.x = max(box1.min.x, box2.min.x);        boxIntersect->max.x = min(box1.max.x, box2.max.x);        boxIntersect->min.y = max(box1.min.y, box2.min.y);        boxIntersect->max.y = min(box1.max.y, box2.max.y);        boxIntersect->min.z = max(box1.min.z, box2.min.z);        boxIntersect->max.z = min(box1.max.z, box2.max.z);    }    // They intersected    return true;}//---------------------------------------------------------------------------// intersectMovingAABB//// Return parametric point in time when a moving AABB collides// with a stationary AABB.  Returns > 1 if no intersectionfloat   intersectMovingAABB(    const AABB3 &stationaryBox,    const AABB3 &movingBox,    const Vector3 &d) {    // We'll return this huge number if no intersection    const float kNoIntersection = 1e30f;    // Initialize interval to contain all the time under consideration    float   tEnter = 0.0f;    float   tLeave = 1.0f;    //    // Compute interval of overlap on each dimension, and intersect    // this interval with the interval accumulated so far.  As soon as    // an empty interval is detected, return a negative result    // (no intersection.)  In each case, we have to be careful for    // an infinite of empty interval on each dimension    //    // Check x-axis    if (d.x == 0.0f) {        // Empty or infinite inverval on x        if (            (stationaryBox.min.x >= movingBox.max.x) ||            (stationaryBox.max.x <= movingBox.min.x)        ) {            // Empty time interval, so no intersection            return kNoIntersection;        }        // Inifinite time interval - no update necessary    } else {        // Divide once        float   oneOverD = 1.0f / d.x;        // Compute time value when they begin and end overlapping        float   xEnter = (stationaryBox.min.x - movingBox.max.x) * oneOverD;        float   xLeave = (stationaryBox.max.x - movingBox.min.x) * oneOverD;        // Check for interval out of order        if (xEnter > xLeave) {            swap(xEnter, xLeave);        }        // Update interval        if (xEnter > tEnter) tEnter = xEnter;        if (xLeave < tLeave) tLeave = xLeave;        // Check if this resulted in empty interval        if (tEnter > tLeave) {            return kNoIntersection;        }    }    // Check y-axis    if (d.y == 0.0f) {        // Empty or infinite inverval on y        if (            (stationaryBox.min.y >= movingBox.max.y) ||            (stationaryBox.max.y <= movingBox.min.y)        ) {            // Empty time interval, so no intersection            return kNoIntersection;        }        // Inifinite time interval - no update necessary    } else {        // Divide once        float   oneOverD = 1.0f / d.y;        // Compute time value when they begin and end overlapping        float   yEnter = (stationaryBox.min.y - movingBox.max.y) * oneOverD;        float   yLeave = (stationaryBox.max.y - movingBox.min.y) * oneOverD;        // Check for interval out of order        if (yEnter > yLeave) {            swap(yEnter, yLeave);        }        // Update interval        if (yEnter > tEnter) tEnter = yEnter;        if (yLeave < tLeave) tLeave = yLeave;        // Check if this resulted in empty interval        if (tEnter > tLeave) {            return kNoIntersection;        }    }    // Check z-axis    if (d.z == 0.0f) {        // Empty or infinite inverval on z        if (            (stationaryBox.min.z >= movingBox.max.z) ||            (stationaryBox.max.z <= movingBox.min.z)        ) {            // Empty time interval, so no intersection            return kNoIntersection;        }        // Inifinite time interval - no update necessary    } else {        // Divide once        float   oneOverD = 1.0f / d.z;        // Compute time value when they begin and end overlapping        float   zEnter = (stationaryBox.min.z - movingBox.max.z) * oneOverD;        float   zLeave = (stationaryBox.max.z - movingBox.min.z) * oneOverD;        // Check for interval out of order        if (zEnter > zLeave) {            swap(zEnter, zLeave);        }        // Update interval        if (zEnter > tEnter) tEnter = zEnter;        if (zLeave < tLeave) tLeave = zLeave;        // Check if this resulted in empty interval        if (tEnter > tLeave) {            return kNoIntersection;        }    }    // OK, we have an intersection.  Return the parametric point in time    // where the intersection occurs    return tEnter;}
